Product Overview
160kVA dry resin transformer is designed as a small, three phase, oil free, fire resistant, and environmentally friendly distribution transformer with epoxy resin cast insulation, pursuing high efficiency and reliability in various industrial and commercial applications. With its robust and compact design, it ensures safe operation without the need for external coolant. The 160kVA dry resin transformer provides reliable power distribution while minimizing environmental impact. Manufactured using environmentally friendly materials and precision equipment, it boasts superior durability, low maintenance, and energy efficiency, making it ideal for meeting high demand electrical needs. It can operate safely for extended periods in indoor, basement, small factory, building, and computer room environments, and is widely used in industrial, construction, municipal, and overseas small power grid applications.
Our 160kVA dry resin transformers have a wide range of applications: they can be used as step down transformers to meet various voltage conversion needs, in small transformer systems for medium capacity applications, or as thre phase transformers in industrial power systems. Thanks to their reliable performance, standardized design, and mature standardized production, delivery times are short. We manufacture strictly according to multiple international and regional standards: IEC, GB, JIS, ANSI, IEEE, and UL, while also meeting energy efficiency ratings (Level 1/Level 2) and SCB series requirements. All products have passed rigorous testing and certification according to the relevant standards.
Technical Specifications
|
Number |
Technical grade |
|
Model number |
Drying type converter for drying oil |
|
Constant capacity |
160kVA (Adjustable demand system) |
|
Imported electricity (Gaogu) |
6.6kV,10kV,11kV,20kV,22kV,22.9kV,35kV(Adjustable demand system) |
|
Export electricity (low pressure) |
0.38kV,0.4kV,(Adjustable demand system) |
|
Voltage regulation range |
±5%,±2×2.5%,(Adjustable demand system) |
|
Number of phases |
Three phase(Adjustable demand system) |
|
Frequency |
50Hz/60Hz |
|
Link Group |
Dyn11,Yyn0,Yd11,Dyn5,YNd11(Adjustable demand system) |
|
Winding material |
Aluminum/Copper |
|
No load loss |
(Adjustable demand system) |
|
Load loss |
(Adjustable demand system) |
|
No load current |
(Adjustable demand system) |
|
Temperature rise limit |
100K,125K(Corresponding to F/H class insulation)(Adjustable demand system) |
|
Short circuit impedance |
(Adjustable demand system) |
|
Cooling method |
AN (natural cooling) or AF (forced air cooling) |
|
Insulation class |
Class F (Class H optional) |
|
Partial discharge |
≤5pC |
|
Implementation Standards |
IEC,GB,JIS,ANSI,IEEE,UL |
Dry Type Transformer FAQ
1. Can you customize dry-type transformers?
Yes. Custom voltage, capacity, tapping range, enclosure type, paint color, and customer logo on nameplate.
2. What certifications do your dry-type transformers have?
ISO9001, CE, CB. UL, CSA, EAC, SASO available upon request.
3. Do you provide installation guidance for dry-type transformers?
Yes. Remote instruction (video, manual) or on-site supervision by our engineers.
Usage scenario
Why Choose Union Power
● Accessories – Fault indicators, cable terminals, etc.
● Installation – On‑site or remote by certified electricians/engineers.
● Commissioning & Testing – Advanced equipment, pro operators, safe power supply.
● After‑Sales – 24/7 online support; on‑site within 5 days.
● Customization – Tailored one‑stop solutions for your needs.
Delivery – Fast, reliable, multiple bases, strict QC.
